MANUAL FOAM WATER MONITOR

Description

A Manual Foam Water Monitor is a tool, for fighting fires caused by liquids. Its designed to deliver firefighting foam over distances. The Foam Water monitor has a base with swivel joints allowing it to rotate and move vertically. Firefighters can control the nozzle assembly adjusting the flow rate spray pattern and direction of the foam as needed. The monitor is connected to a water supply source. Operated manually using handwheels or levers or sometimes even remotely controlled. Its ability to project foam over areas makes it incredibly valuable, in industries where theres a risk of liquids improving fire response capabilities and ensuring safety in hazardous situations.

Technical Parameter

Aluminum alloy construction
Hand wheel Control;
Flow Rate: 24/32/40/48/64 LPS (optional);
Available for water and foam both;
360° rotation horizontally;
-45° to +90° elevate vertically;
Flange standard: BS4504, ANSI150, GB, etc.
NFPA Compliance

Technical Parameter

Model	E0304-L24H	E0304-L32H	E0304-L40H	E0304-L48H	E0304-L64H
Flow Rate	1440 LPM	1920 LPM	2400 LPM	2880 LPM	3840 LPM
Working pressure	10 bar	10 bar	10 bar	10 bar	12 bar
Foam Jetting Range	40 m	45 m	50 m	55 m	60 m
Water Jetting Range	45 m	50 m	55 m	60 m	65 m
Foam Expansion	≧ 6 times	≧ 6 times	≧ 6 times	≧ 6 times	≧ 6 times
Rotation Horizontally	360°	360°	360°	360°	360°
Elevate Vertically	-45° to +90°	-45° to +90°	-45° to +90°	-45° to +90°	-45° to +90°
Inlet	DN100 (4”)	DN100 (4”)	DN100 (4”)	DN100 (4”)	DN100 (4”)
Outlet	2.5” NH	2.5” NH	2.5” NH	2.5” NH	2.5” NH
