This is a tiller control stainless steel monitor with Standard DN65 waterway size to support an Max. Flow rate up to 2400LPM with less turbulence. Full set of monitor assembly are fully enclosed for long service life. It’s designed for rough and high corrosion condition. The monitor can be used with smooth bore, constant flow, selectable flow, automatic and foam pipe nozzle. w/o deflector
| Model Number | ES0304-ES01 | |
|---|---|---|
| Operation Type | Tiller Controlled | Tiller Controlled |
| Installation | Flange | Flange |
| Flange Inlet | 2.5Inch, 3 Inch, 4 Inch ANSI, BS, JIS, DIN | 3 Inch, 4 Inch, 6 Inch ANSI, BS, JIS, DIN |
| Waterway Size | DN65 | DN80 |
| Outlet Size | 1.5” Or 2.5” NH Male For Choice | 2.5” Or 3” NH Male For Choice. |
| Max. Flow Rate | 40LPS, 2400LPM. 650GPM @ 8 Bar | 80LPS, 4800LPM. 1250GPM @ 8 Bar |
| Horizontal Angle | 360°, Or according to customized request | 360°, Or according to customized request |
| Vertical Angle | -45° to +80°, Or according to customized request | -45° to +80°, Or according to customized request |
| Standard Color | RAL 3000 Or Polished Stainless Steel | RAL 3000 Or Polished Stainless Steel |
