F-500 STORED PRESSURE

FIRE EXTINGUISHER

ES F500 STORED PRESSURE FIRE EXTINGUISHER Description Page
  • ES-F500 is a multiple-purpose firefighting agent which is ideal for Class A It is the only agent proven to extinguish
  • lithium-ion batteries, without reignition It is completely fluorine-free, contains no
  • PFOA, PFOS or any fluorine ingredients It is non-corrosive, non-toxic,
  • Non-hazardous and fully biodegradable

Technical Data

ES-F500 Technical Data
Stock Code ES-F500
Size 9.0L
Fire Rating 3A
Agent F-500 Multi-Purpose Encapsulator Agent
Propellant Dry nitrogen
Operating Pressure 10 bar
Extinguisher Height 638mm
Cylinder Height 541mm
Cylinder Width 180mm
Cylinder Volume 12.5L
Cylinder Finish High UV resistance
Full Weight 12.2kg
Test Pressure 25 bar

Material

ES-F500 Material
Valve Nickel plated brass
Handle/Lever Stainless steel
Check Stem Stainless steel
Cylinder Stainless steel
Cylinder Finish Coated with epoxy polyester paint
Hose Assembly PA6 & EPDM & Brass
Pressure Gauge Stainless steel

Standard Approval

  • AS/NZS 1841.2
  • Global-Mark ID: 109076
eurosafe es f500
  • SMART PHONES
  • LAPTOPS & TABLETS
  • SOLAR PANELS HYBRID & ELECTRIC CARS
  • MOBILITY SCOOTERS
  • GOLF CARTS
ES F500 Foam Concentrate Description Page
  • Available in 4L, 9L and all wheeled type fire extinguishers 20L, 200L, and 1000L Drums
